These features enable users to monitor sources using the internal Waveform and Vector Scope. Waveform Wide mode* is supported, and both Waveform and Vector Scope can be displayed simultaneously.
* OBM-U170 Model is Only Supported.
• High Dynamic Range(HDR) Display Function
The OBM series provides the function to display the High Dynamic Range footage. Postium HDR function allows users to view both highlights and shadow detail of scenes at the same time, thus resulting in more natural and realistic images. The OBM series supports PQ EOTF (SMPTE ST 2084), Hybrid Log Gamma and S-Log3.
OBM-HDR provides the function of comparing HDR and SDR(Standard Dynamic Range) on the displayed image on the OBM series simultaneously.
• Focus Assist
This function controls the aperture level of a video signal, and displays images on screen with sharpened edges to help camera focus operation.
• Various 4K/12G Display Modes
Single Link 12G-SDI
Dual Link 2-Sample Interleave(2-S.I.) (*OBM-U Series : Supports up to 2160/60p. OBM-W Series : Supports up to 2160/30p)
Quad Link 2 Sample Interleave (2-S.I.)
Each link contains a full image at 1/4 resolution. 2-S.I. mode uses four Sub-image and alternates the samples every two pixels and every line instead of slitting the image into four quadrants.
Quad Link Square DivisionEach link contains one square of the original image.
• Fast Mode
This function minimize the interlaced video processing time delay. This mode is also useful when displaying fast-motion interlaced video content and when reducing the delay between video and audio.
Internal Video Processing Time
• False Color
This function evaluates the Luma(Y') level of the input image. If the certain Y' level is set, the pixels with the designated Luma(Y') level are displayed with the zebra pattern or the color pattern. There are three modes in OBM False Color.
• Adjustable Gamma
Gamma value is adjustable from 1.0 to 3.0 as user’s preference to monitor in the dark area of the picture. Any pictures taken in either light or dark environment can be easily watched or analyzed.
• 12G-SDI over IP Supporting ST 2022-6
The OBM-U and OBM-W series have the SFP interface, which allows to use the various SFP modules which can fit any possible broadcast applications. The OBM-U and OBM-W series monitors can display the 12G-SDI over fiber and the 12G-SDI Single Link over IP through the integrated SFP interface.
• Camera Log Selection
The OBM series has the integrated camera LUT of the various camera manufacturers. It allows users to load the following camera logs. Log-C / C-Log / S-Log2, S-Log3 / J-Log1 The more camera LUTs will be updated.
• Camera Log Mapped SDI Loopout
This function allows to load the camera log to the original image and then send the camera log mapped image to another monitor through SDI loop out.
• Remote Control via Ethernet
The OBM series can be connected via Ethernet connection and controlled remotely on the network.
• Closed Caption
The OBM series can display closed captions with an SDI input. It supports the CEA-708(HD-SDI closed captioning standard) and CEA-608(SD-SDI closed captioning standard).
• Waveform & Vector Scope Position Changeable
The position of Waveform and Vectro Scope can be changed among Left Top, Right Top, Right Bottom, Left Bottom.
• System Date Copy
This function allows users to save the monitor configuration and adjustment settings on the USB memory stick and load them to other monitors. This is useful for multiple monitor systems, allowing the transfer of one monitor’s setup and adjustment data to another.
• Waveform, Vector Scope Size Adjustable
The image size of Waveform and Vector Scope can be changed between Small and Large.
• Various Markers
The OBM series can display various markers, including aspect marker, area marker, and center marker. In addition, the detailed display settings of each marker are allowed. For example, the color, brightness, horizontal/vertical position, and thickness of aspect markers can all be adjusted.
• HDR / Camera Log Comparison
The unique function allows users to compare HDR and Camera Log side by side. The comparison area can be moved and selected by using the vertical Wipe pattern.
• HDR Waveform
When HDR more is set on, HDR Waveform is displayed on screen.
• In-Monitor Display(IMD) Function
The image source names and tally information can be displayed on the screen, with an external remote function via Ethernet. The TSL system protocol is supported. The color of the source name and tally color can be selectable among White, Red, Green, Blue, Yellow, Cyan, Magenta.
• Password Lock for User Preset
When multiple users share the same monitor, each user can register his/her own password for color temperature and user preset data. This ensures the users correctly recall their preset data, and keep preset information safe from unauthorized use.
• Custom 3D LUT File Import
The OBM series allow the user to import 3D Look-up Table for accurate and consistent color matching between individual displays as well as using customized ‘looks’ that have been created by 3rd party color-grading applications. 32ˆ³ and 64ˆ³ cube file are supported.
• Scan Mode
When the 4096 x 2160(1.89:1) signal is fed to the 1920x1080(16:9) resolution sceen, if you select Zero Scan mode, the whole picture is displayed on the screen, with maintaining 1.89:1 ratio.
